Connector electrical specifications
connection 1
Connector SMA-Male-RP
| Frequency | DC – 7.125 GHz |
|---|---|
| Impedance (Ohm) | 50 |
| VSWR | 1.3 |
| Max. Input Power (W) | 25 |
2JC260G
Connector
SMA-Male-RP Surface Mount Connector
Connections (1)
| Mounting | Surface Mount Connector |
|---|---|
| Connector type | SMA |
| Connector Gender | Male (Plug) |
| Connector polarity | Reverse polarity |
| Dimensions (mm) | 6.35 × 6.35 × 11.8 |
| Body Material | Brass |
| Body Plating | Gold |
| Contact Material | Brass |
| Contact Plating | Gold |
| Insulator Material | Teflon |
| Operating temperature | -40 °C to +85 °C |
| Storage Temperature | -40 °C to +85 °C |
| Substance Compliance | RoHS |
| Standard colors |
Product added to cart
Products documents
Key Features
SMA-Male-RP
Surface Mount
Reverse Polarity connector
Gold Plated
Applications
