Antenna and electrical specifications
connection 1
2.4/5.0 GHz ISM
| Standards | WiFi, BT, ZigBee, ISM |
|---|---|
| Frequency | 2410-2490, 4920-5925 |
| VSWR | ~1.3:1, ~1.4:1 |
| Efficiency (%) | ~62.6, ~47.0 |
| Peak Gain (dBi) | ~2.5, ~1.5 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
