Key Features

  • GPS/GLONASS/QZSS/Galileo
  • Heavy Duty antenna
  • Ground Plane Dependent
  • Screw Mount
  • Anti-Rotation Mechanism
  • Post-Filter
  • Certificates: IP67, IP69K, IK09
  • Customizable Cable and Connector

Antenna and electrical specifications

connection 1

CELLULAR

Standards 2G and 3G
Frequency 824-960, 1710-2170
VSWR ~2.1:1, ~1.7:1
Efficiency (%) ~43, ~38
Peak Gain (dBi) ~1.8, ~2.3
Impendance (Ohm) 50
Polarisation Linear
Max. Input Power (W) 25
connection 2

GPS/GLONASS

Standards GPS/QZSS/Galileo/GLONASS
Frequency 1575.42, 1598-1610
Impedance (Ohm) 50
Active Gain (dB) 23 @ 3V, 24 @ 5V
Voltage (V) 2.7 - 5.5
Current (mA) 22 @ 5V
Power Consumption (mW) max 138
Saw Filter Type Post-Filter
