Antenna and electrical specifications
CELLULAR
| Standards | 2G and 3G |
|---|---|
| Frequency | 824-960, 1710-2170 |
| VSWR | 4.0:1, 6.0:1 |
| Efficiency (%) | ~ 37.8, ~ 38.7 |
| Peak Gain (dBi) | ~ 1.1, ~ 1.3 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
| Standards | 2G and 3G |
|---|---|
| Frequency | 824-960, 1710-2170 |
| VSWR | 4.0:1, 6.0:1 |
| Efficiency (%) | ~ 37.8, ~ 38.7 |
| Peak Gain (dBi) | ~ 1.1, ~ 1.3 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
