2JE17 Antenna

Cellular High Performance Fiberglass Embedded Antenna

General specification
Frequency
3G/2G/CELL
Mounting Surface Mount Fiberglass
Dimensions (mm) 26 x 7.6 x 3
Operating temperature -40 °C to +85 °C
Shear Force Test Minimum specified shear force: 50 kgf
Get Datasheet
Product added to cart

Key Features

  • High Performance
  • Embedded Antenna
  • Low Cost
  • Surface Mount
  • Fiberglass Material
  • Antenna and electrical specifications

    connection 1

    CELLULAR

    Standards 2G and 3G
    Frequency 824-960, 1710-2170
    VSWR ~3.3:1, ~1.8:1
    Efficiency (%) ~67.5, ~70.8
    Peak Gain (dBi) ~2.2, ~2.2
    Impendance (Ohm) 50
    Polarisation Linear
    Max. Input Power (W) 25
