Antenna and electrical specifications
GPS/GLONASS/BeiDou
Standards | GPS/GLONASS/BeiDou/QZSS/Galileo |
---|---|
Frequency | 1561.098, 1575.42, 1598-1606 |
VSWR | ~1.8:1, ~1.9:1, ~2.1:1 |
Efficiency (%) | ~75.6, ~73.1, ~74.6 |
Peak Gain (dBi) | ~3.8, ~3.6, ~3.8 |
Impedance (Ohm) | 50 |
Radiation Pattern | Hemispherical |
