Antenna and electrical specifications
connection 1
CELLULAR
| Standards | 2G and 3G |
|---|---|
| Frequency | 824-960, 1710-2170 |
| VSWR | ~1.6:1, ~1.7:1 |
| Efficiency (%) | ~52.2, ~40.7 |
| Peak Gain (dBi) | ~1.3, ~0.6 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 100 |
