Antenna and electrical specifications

connection 1

CELLULAR/4G LTE

Standards 2G,3G and 4G
Frequency 698-960, 1710-2170, 2500-2700
VSWR ~1.8:1, ~1.3:1, ~2.0:1
Efficiency (%) ~53, ~49, ~25
Peak Gain (dBi) ~2.4, ~1.3, ~0.4
Impedance (Ohm) 50
Polarisation Linear
Max. Input Power (W) 25
connection 2

GPS/GLONASS

Standards GPS/QZSS/Galileo/GLONASS
Frequency 1575.42, 1598-1606
VSWR <=1.4:1
Impedance (Ohm) 50
Polarisation RHCP
Active Gain (dB) 28 @ 2.7 V
Voltage (V) 1.5 – 3.6
Current (mA) 9 Typ
Power Consumption (mW) 24.3 Typ

Key Features

GPS/GLONASS/QZSS/Galileo
Adhesive Mount
Ground Plane Independent
Customizable Cable and Connector
certificates: IP67, IP69
