2JCP2540101Ca Antenna

GPS/GLONASS/BeiDou/Galileo High Gain Ceramic Passive Antenna

General specification
Frequency
GPS/GLO/BEI/QZSS/Galileo/L1
Mounting Thru-Hole Mount Ceramic
Note Specification only for the 2JDK0201Ca-A28 Development Kit
Dimensions (mm) 25 x 25 x 4
Operating temperature -40 °C to +85 °C
Get Datasheet
Product added to cart

Key Features

  • High Gain
  • Ceramic Passive Antenna
  • Thru-Hole Mount
  • 25 × 25 × 4 mm
  • GPS/GLONASS/BeiDou/QZSS/Galileo
  • Ground Plane Dependent
  • Antenna and electrical specifications

    connection 1

    GPS/GLONASS - Ceramic Passive Antenna

    Standards GPS/GLONASS/BeiDou/QZSS/Galileo
    Frequency 1561.098, 1575.42, 1598-1606
    Passive Gain (dBi) ~4.2, ~4.5, ~5.0
    Efficiency (%) ~72.2, ~79.7, ~81.6
    50
    Radiation Pattern Hemispherical
    Polarization RHCP
