Antenna and electrical specifications
connection 1
2.4 / 5.0 / 6.0 GHz Tri-Band WIFI 6E / WIFI 7
| Standards | WiFi, BT, ZigBee, ISM, SigFox, LoRa |
|---|---|
| Frequency | 2410-2490, 4920-5925, 5925-7125 |
| VSWR | ~1.2:1, ~1.5:1, ~1.6:1 |
| Efficiency (%) | ~50.1, ~46.8, ~45.1 |
| Peak Gain (dBi) | ~5.5, ~6.2, ~4.7 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
connection 2
2.4 / 5.0 / 6.0 GHz Tri-Band WIFI 6E / WIFI 7
| Standards | WiFi, BT, ZigBee, ISM, SigFox, LoRa |
|---|---|
| Frequency | 2410-2490, 4920-5925, 5925-7125 |
| VSWR | ~1.3:1, ~1.7:1, ~2.0:1 |
| Efficiency (%) | ~50.3, ~45.5, ~40.4 |
| Peak Gain (dBi) | ~4.0, ~6.1, ~5.1 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 25 |
