2J6024MPa Antenna

Falcon 2 x 4G LTE/3G/2G MIMO Compact Ultra Versatile Antenna

General specification
Frequency
2× 4GLTE MIMO/FirstNet/LPWA/NB-IoT/Cat-X-Mx-NBx/3G/2G
Mounting Magnetic/Adhesive Mount, Adhesive Mount, Magnetic Mount
Dimensions (mm) 80 x 76 x 13
Operating temperature -40 °C to +85 °C
Note Specification subject to change
Standard colors
Get Datasheet
Product added to cart

Key Features

  • Ground Plane Independent
  • Customizable Cable and Connector
  • Low Profile
  • Magnetic/Adhesive Mount
  • Antenna and electrical specifications

    connection 1

    CELLULAR/4G LTE

    Standards 2G,3G and 4G
    Frequency 698-960, 1710-2170, 2500-2700
    VSWR ~2.2:1, ~2.6:1, ~2.1:1
    Efficiency (%) ~25.3, ~20.2, ~36.1
    Peak Gain (dBi) ~-0.7, ~1.7, ~4.4
    Impendance (Ohm) 50
    Polarisation Linear
    Max. Input Power (W) 25
    connection 2

    CELLULAR/4G LTE

    Standards 2G,3G and 4G
    Frequency 698-960, 1710-2170, 2500-2700
    VSWR ~2.5:1, ~2.5:1, ~2.2:1
    Efficiency (%) ~25.7, ~22.5, ~35.2
    Peak Gain (dBi) ~0.8, ~1.8, ~4.5
    Impendance (Ohm) 50
    Polarisation Linear
    Max. Input Power (W) 25
