Antenna and electrical specifications
CELLULAR
| Standards | 2G and 3G |
|---|---|
| Frequency | 824-960, 1710-2170 |
| VSWR | ~1.7:1, ~2.2:1 |
| Efficiency (%) | ~60.6, ~41.5 |
| Peak Gain (dBi) | ~1.9, ~0.7 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 100 |
| Standards | 2G and 3G |
|---|---|
| Frequency | 824-960, 1710-2170 |
| VSWR | ~1.7:1, ~2.2:1 |
| Efficiency (%) | ~60.6, ~41.5 |
| Peak Gain (dBi) | ~1.9, ~0.7 |
| Impedance (Ohm) | 50 |
| Polarisation | Linear |
| Max. Input Power (W) | 100 |
